Subdistribution board without functional integrity
985761
Subdistribution board, light grey (RAL 7035)
Subdistribution board For RZB LUXIFAIR central battery systems. Wall-mounted housing made of PVC. Colour light grey (RAL 7035). Door hinge: right. Cable entry from above. 3 power feed terminals.
Technical Specifications
| Type of Installation | Wall (surface) |
|---|---|
| Construction of system | Modular |
| Outgoing circuits | 4 |
| Maximum connection power per final circuit | 580 W |
| Luminaires per final circuit | 20 |
| Luminaire monitoring | Single luminaire monitoring , Circuit monitoring |
| Mixed operation | Yes |
| Number of circuit modules | 1 |
| Potential operating modes | Non-maintained , Maintained , Switched maintained , Staircase light switching |
| Switching power | 4000 W |
| Max. Switching power | 4000 VA |
| Output voltage mains | AC 230 V / DC 216 V |
| Input voltage | AC 230 V / DC 216 V |
| Terminal blocks (infeed) | 16 mm² |
| Terminal blocks max. (output circuits) | 2.5 mm² |
| Switching power | 4000 VA |
| Type of protection | IP 20 |
| Protection class | I |
| Length L | 110 mm |
| Width B | 295 mm |
| Height H | 385 mm |
| Weight | 7 kg |
Downloads
Modules and assemblies
985846
Switch sensor module 230 V
985844
Switch sensor module 230 V
985845
Switch sensor module 24 V
985843
Switch sensor module 24 V
985497
3-phase network monitoring module for Bus communication, for DIN-rail mounting
09-6302.0177
3-phase network monitoring module with test function
